Trimble Mini 360 Prism

Image of Trimble Mini 360 Prism

Description

The Trimble Mini 360 Prism is a 0.5” (12.7mm) surveying prism for the RMT 606/604. It has an in-built bubble to help keep the prism level.

This surveying prism is used in conjunction with the RMT606 (P/N. 572204610) or the RMT604 as a remote target for Trimble 5600 series. It can be used for distances up to 350 m.

Specifications

Model:Mini 360 Prism
Manufacturer:Trimble
MPN:571204312
Height Offset:30.0 mm
Absolute constant: +2.00 mm
Leica constant: +36.40 mm
Weight:250 g
Mount:5/8" Thread

Trimble Mini 360 Prism FAQ

Below is a list of frequently asked questions about Trimble Mini 360 Prism.

What is the prism constant for the Trimble Mini 360 Prism?

The absolute prism constant (true value) for the Trimble Mini 360 Prism is 2.0mm. The prism constant as defined for Leica instruments for Trimble Mini 360 Prism is 36.4mm. For a more detailed explanation on prism constants please see this article.

Can I use the Trimble Mini 360 Prism with a Leica instrument?

Yes, you can use the prism with a Leica instrument as long as you set up the correct prism constant in the instrument settings.

What is the prism constant value that I need to use with a Leica instrument?

In order to use the Trimble Mini 360 Prism with a Leica instrument you should use 36.4mm as the prism constant value.

What is the height offset of the Trimble Mini 360 Prism?

The Trimble Mini 360 Prism height offset is 30.0mm. This is measured from the mounting point to the centre of the prism.
