AutoCAD – How to fillet elements with the Fillet Tool

In this article I will explain the fillet tool in AutoCAD & how to fillet 2D and 3D elements.

What is a fillet?

A filet is term used in many industries and can be defined in different ways, but it simple terms it is a rounded sharp edge or corner. In AutoCAD you’ll often often see the word round used, but the word is synonymous with fillet. The general consensus within AutoCAD is that an inside corner is called a fillet and an outside corner is called a round.

Fillet vs other design element

Very often fillets are easily confused with other design features such as chamfers and bevels. Whilst the these features design elements have a common purpose, they aren’t interchangeable and typically have a different use-case.

Bevel
Bevel
Fillet
Fillet
Chamfer
Chamfer

Fillet – A fillet or round connects two objects with a tangent arc in 2D, or creates a rounded transition between the adjacent faces of a 3D solid.

Chamfer – A chamfer connects two objects with an angled line in 2D, or creates an angled face between the adjacent faces of a 3D solid.

Bevel – Similar to a chamfer, a bevel connects two objects with and angled line in 2D or creates an angled face between adjacent faces of a solid in 3D.

As you can see, chamfers and bevels are pretty much the same thing, at least from AutoCAD’s perspective. However, there is a slight difference which defines which term is appropriate for use. The difference is: a chamfer is typically a 45° angle added to the edge of a feature, while a bevel is a slope from a horizontal or vertical edge.

Types of fillet

Fillets can be classified in a few different categories, depending on a several factors. On a day to day basis you will encounter the following types of fillets in AutoCAD:

Fillet based on profile

Depending on the cross profile of the fillet, these can be categorised into:

  • mitre (which is for all intents and purposes a chamfer)
  • convex (the profile creates a convex shape)
  • concave (the profile creates a concave shape)
Mitre fillet example
Mitre Fillet
Convex fillet example
Convex Fillet
Concave fillet example
Concave Fillet

Fillet based on object type

If you categorise fillets based on the objects they are applied to, then these can be split into the following two categories:

  • 2D fillet – a fillet applied in a 2D space for objects such as lines and arcs.
  • 3D fillet – a fillet applied in a 3D space at the corners of solid objects.
2D Fillet Example
2D Fillet Example
3D Fillet Example
3D Fillet Example

Fillet based on corner type

Depending on the corner type of an object a fillet is generally categorised in AutoCAD into two categories:

  • fillet – when it is added to an inside corner
  • round – when it is added to an outside corner
Fillet example
Fillet example
Round example
Round example

Objects that can have a fillet applied

There are a large number of objects within AutoCAD that can have a fillet (or round) applied to them. These include 2D and 3D primitive objects. The full list of object in AutoCAD that can have a fillet applied to them is as follows:

  • 2D polylines
  • 3D solids and surfaces (not available in AutoCAD LT)
  • Arcs
  • Circles
  • Ellipses and elliptical arcs
  • Lines
  • Rays
  • Splines
  • X-lines

AutoCAD – how to fillet 2D Elements

As mentioned above, a round or fillet can be created between two objects of the same or different object types: 2D polylines, arcs, circles, ellipses, elliptical arcs, lines, rays, splines, and x-lines.

If the two selected objects are on the same layer, the arc defined is created on that layer. Otherwise, the arc is created on the current layer. The layer affects object properties including color and linetype.

An abstract workflow of adding a fillet on two compatible objects is described below. Please note that there are different variations depending on the object types selected. There are also multiple options that can be applied to the fillet such as trim mode.

AutoCAD – How to Fillet – Abstract Example

In order to successfully apply a fillet in AutoCAD you must keep in mind the following:

  • Objects must be of compatible types (listed above).
  • Lines must not be parallel. If these are parallel your fillet command will not work.
  • Depending on the object type you will have variation in the options. Make sure you apply these before selecting the second object.

Now, follow these steps in AutoCAD in order to apply a fillet:

Step 1 – Run the FILLET Command

Select the Fillet option from the Modify tab group

AutoCAD Fillet Command in Modify Tab Group
AutoCAD Fillet Command in Modify Tab Group

or run the FILLET command.

Typing the Fillet Command
Typing the Fillet Command

Step 2 – Set the fillet radius

Right-Click anywhere in the Model Space and select Radius to define a radius for the fillet.

Right-Click to enter Fillet Radius
Right-Click to enter Fillet Radius

You can either enter the value of the radius in your desired units or define it as a distance on the screen.

Type in the Fillet Radius
Type in the Fillet Radius

Alternatively, you can type in R in the command line to set the same value via commands.

Use the command line and type R for Fillet Radius
Use the command line and type R for Fillet Radius

Step 3 – Select the first object

Select the first of the object you want to fillet. This can be any of the compatible objects listed above.

Fillet - Select first object
Select first object

Step 4 – Select the second object to apply

Select the second object to define the fillet to complete the command.

Fillet - Select second object
Select second object

Step 5 – Results

Once finalised, the fillet will be applied between the two selected objects with the specified radius.

Fillet - Results
Results

The two objects will be modified and trimmed if this option was selected (default).
